Key Specifications :
| Design Type | Z-Shape (Vertical + Horizontal combination) |
| Structure Material | Stainless Steel (SS304/SS316) / Mild Steel (MS) Powder Coated |
| Bucket Material | Food-grade Polypropylene (PP) / ABS / SS / Nylon |
| Bucket Size | 100 mm to 1 MTR wide (commonly: 4 ltr, 6ltr, 9 ltr) |
| Bucket Pitch | 150 mm to 500 mm (based on bucket size and application) |
| Belt/Chain Type | Rubber Belt / PVC Food Grade Belt / SS Chain / Plastic Modular Chain |
| Lifting Height | Up to 10 meters (customizable as per plant layout) |
| Horizontal Length | Customizable based on loading/unloading position |
| Capacity | 1 TPH to 10 TPH (Tons Per Hour) or more, depending on bucket and speed |
| Motor Power | 0.5 HP to 3 HP (based on size & material) |
| Drive Type | Geared Motor (Helical/Worm), Mounted on Top Section |
| Feeding System | Manual / Vibratory Feeder / Hopper |
| Discharge System | Automatic flap / gravity / centrifugal |
| Speed Control | VFD (Variable Frequency Drive) - Optional |
| Cleaning Door | Provided for hygiene & maintenance (especially in food-grade models) |
| Safety Features | Overload protection, belt tracking system, interlocks |
| Frame Finish | Matt/Glossy Polished SS or Powder Coated MS |
Optional Features :
- Detachable buckets
- Dustproof enclosure
- Hopper with level sensor
- Auto start/stop via sensor
- Mobile base with castor wheels
