Key Specifications :
| Conveyor Type | Flexible / Mobile / Fixed Belt Conveyor |
| Structure Material | Mild Steel (MS) Powder Coated / Stainless Steel (SS304) |
| Conveyor Belt Material | PVC / PU / Rubber / Food Grade Belt |
| Conveyor Length | 6 to 30 meters (customizable) |
| Conveyor Width | 400 mm to 1000 mm (standard: 600/800 mm) |
| Height Adjustment | Manual or Motorized Hydraulic System (700 mm to 2500 mm adjustable) |
| Lifting Mechanism | Hydraulic Cylinder / Screw Jack / Motorized Lift |
| Belt Speed | 10 to 30 meters per minute (with VFD control – optional) |
| Load Capacity | 50 to 100 kg/meter (customizable for heavy-duty use) |
| Drive Motor | 1 HP to 5 HP Geared Motor (AC Motor, 3 Phase or Single Phase) |
| Power Supply | 230V/415V AC, 50 Hz |
| Mobility | Swivel Castor Wheels with Brakes |
| Conveyor Type | Incline / Horizontal / Telescopic / Slat / Roller (as per application) |
| Frame Finish | Powder Coated / Painted / SS Polished |
| Inclination | 10° to 25° depending on height & space |
| Control Panel | Forward/Reverse Switch, Emergency Stop, VFD – Optional |
Optional Features :
- Telescopic extension for inside truck reach
- Reversible belt direction
- Side guides or safety rails
- Auto height adjustment
- PU wheels for smooth rolling
- VFD for speed control
