A Side Wall Cleated Belt Conveyor is used to move bulk or unit material at steep inclines or vertically. It features a corrugated side wall and cleats on the belt to prevent the material from sliding or falling back.
Key Specifications :
| Conveyor Type | Side Wall Cleated Belt Conveyor |
| Belt Type | Corrugated Sidewall Belt with Cleats (integrated or attached) |
| Belt Material | Rubber / PVC / PU (food grade optional) |
| Belt Width (Base) | 300 mm to 1000 mm |
| Conveyor Length | 2 m to 30+ m (based on layout) |
| Cleat Height | 25 mm / 50 mm / 75 mm / 100 mm / 150 mm |
| Sidewall Height | 40 mm to 200 mm |
| Cleat Type | T-type / L-type / S-type (custom based on material) |
| Conveying Angle | 30° to 90° (vertical possible) |
| Speed | 0.1 – 1.5 m/s (variable via VFD) |
| Drive Motor | 0.5 HP to 5 HP (SEW / Bonfiglioli / Local) |
| Drive Type | Gear Motor – Direct / Chain Drive |
| Frame Material | MS Powder Coated / SS 304 / Aluminum |
| Support Structure | Box or tubular section with base plates or wheels |
| Load Capacity | 50 – 300 kg/meter (based on design) |
| Discharge Height | As per application (fixed or adjustable) |
| Tensioning System | Screw-type / Gravity-type (custom as per requirement) |
Optional Features :
- Hopper for feeding material
- Discharge chute or hoo
- Dust cover or enclosure
- VFD control panel
- Emergency stop switch
- Cleaning scraper for belt bottom
- Mobile structure with castors
