Key Specifications :
| Application | Municipal Solid Waste (MSW), Industrial Waste, E-waste, Plastic, Metal, Paper |
| Conveyor Type | Flat Belt / Inclined Belt / Sorting Line Conveyor |
| Structure Material | Mild Steel (MS) Powder Coated / Galvanized / Stainless Steel (SS304 for hygiene) |
| Belt Type | Rubber Belt / Chevron Belt / Oil-resistant PVC Belt / Rough Top Belt |
| Belt Width | 600 mm to 1500 mm (Standard: 800 mm / 1000 mm / 1200 mm) |
| Conveyor Length | As per machine bed and discharge point (adjustable) |
| Belt Speed | 0.2 to 1.0 m/s (adjustable via VFD) |
| Motor Power | 1 HP to 5 HP (depends on conveyor size & load) |
| Drive Type | Geared Motor (Helical/Worm), End or Center Drive |
| Frame Height | Adjustable (700 mm to 1200 mm working height) |
| Support Legs | Height-adjustable MS box pipe with base plates |
| Load Capacity | 50 to 200 kg/meter (based on belt and frame strength) |
| Sorting Stations | 2 to 10 (manual or automated) |
| Walkways / Platforms | Optional maintenance walkways with handrails |
| Discharge Points | Manual chute / Side bins / Diverter chutes (custom) |
| Cleaning System | Belt scraper / brush roller (optional) |
| Control Panel | Start/Stop, Emergency Switch, Forward/Reverse, VFD for speed control |
Optional Features :
- Magnetic separator for ferrous metals
- Air separator / blower for light materials
- Trommel or Vibratory feeder before conveyor
- Dust cover or enclosure
- Hopper with vibratory feeder
- LED lighting for sorting area
- Sensor-based automatic sorting (advanced)
