Key Specifications :
| Type | Hinged Belt Type / Scraper Type / Magnetic Chip Conveyor |
| Application | Metal chips, machining scrap, swarf, oil-laden waste |
| Structure Material | Mild Steel (MS) / Stainless Steel (SS304/316 for wet/oil conditions) |
| Conveyor Width | 100 mm to 600 mm (Common: 200–300 mm for CNC use) |
| Conveyor Length | 1 meter to 6 meters (customizable as per machine layout) |
| Conveyor Height | As per machine bed and discharge point (adjustable) |
| Belt Type | Hinged Steel Belt / Drag Chain / Scraper / Magnetic Strip |
| Pitch of Hinged Belt | 25.4 mm / 38.1 mm / 50.8 mm |
| Belt Material | MS / SS Hinge Plate with Perforations for Filtration |
| Belt Speed | 1 to 3 meters per minute (fixed or VFD-controlled) |
| Load Capacity | Up to 150 kg/hour (depends on chip size, type) |
| Motor Power | 0.25 HP to 1 HP (geared motor, 3-phase) |
| Coolant Handling | Perforated belt allows coolant drainage back to tank |
| Drive Type | Geared Motor, Side or End Mount |
| Inclination Angle | 10° to 50° (for lifting and bin discharge) |
| Chip Discharge Height | 500 mm to 1500 mm (customizable) |
| Control Panel | Start/Stop, Auto with CNC Interface (optional), Overload protection |
Optional Features :
- Coolant tank with filtration
- Level sensor for auto start/stop
- Magnetic separator
- Safety interlocks
- Removable collection bin
- VFD for speed control
