Key Specifications :
| Type | Vertical Continuous / Centrifugal Discharge Bucket Elevator |
| Frame Material | Mild Steel (MS) Powder Coated / Stainless Steel (SS304 or SS316) |
| Bucket Material | Plastic (PP / HDPE / ABS) / Stainless Steel / Mild Steel |
| Bucket Size | 100 mm to 500 mm (Common: 160x100 mm, 250x125 mm, 300x180 mm) |
| Bucket Pitch | 150 mm to 400 mm (based on bucket size) |
| Belt/Chain Type | Rubber belt / PVC belt / Steel chain / Plastic modular chain |
| Lifting Height | Up to 30 meters (customizable as per requirement) |
| Capacity | 1 TPH to 25 TPH or more (depending on bucket size and elevator speed) |
| Discharge Type | Centrifugal / Continuous / Positive Discharge |
| Feeding Method | Manual / Hopper / Vibratory Feeder |
| Motor Power | 0.5 HP to 7.5 HP (based on height and load) |
| Drive Type | Helical or Worm Gear Geared Motor (Top-mounted or Bottom-mounted) |
| Speed Control | VFD (Variable Frequency Drive) – Optional |
| Casing | MS / SS enclosed housing with inspection windows |
| Cleaning System | Optional access panels / clean-out doors |
| Inlet/Outlet Position | Bottom feed – Top discharge (fixed or adjustable chute) |
| Noise Level | < 70 dB (quiet operation in enclosed models) |
| Safety Features | Belt alignment sensor, overload protection, interlock switch, anti-return flap |
Optional Features :
- Explosion-proof motor (for chemical plants)
- Dust-tight or water-resistant enclosures
- Hopper with level sensor or vibrator
- Magnet separator at inlet
- Automatic start/stop with sensors
